Introducing Qedit/UX 6.2.01 1
Introduction............................................................................ 1
Qedit for Windows................................................................ 1
Highlights In
Version 6.2.01................................................. 2
Highlights In
Version 6.2...................................................... 2
Highlights In
Version 6.1...................................................... 2
Highlights In
Version 6.0...................................................... 2
Highlights In
Version 5.9...................................................... 2
Highlights In
Version 5.8.01................................................. 3
Highlights In
Version 5.8...................................................... 3
Highlights In Version 5.7...................................................... 3
Compatibility......................................................................... 3
CPU Serial Number
(uname)................................................. 4
Known Problems.................................................................... 4
Documentation....................................................................... 4
User Manual............................................................ 4
Change Notice......................................................... 4
Printed Documentation............................................ 4
Web Download........................................................ 5
Installation 7
Introduction............................................................................ 7
Installation
Assistance........................................................... 7
Step 1: Log On as
Root.......................................................... 7
Step 2: Create
Robelle Directory........................................... 8
Step 3: Restore
Files.............................................................. 8
Step 4: Setting Up
Variables.................................................. 8
Step 5: Setting Up
Links........................................................ 9
Step 6: Start the
Qedit for Windows Server (optional)....... 10
Enhancements Since
Version 5.6 11
Introduction.......................................................................... 11
Qedit for Windows 13
Introduction.......................................................................... 13
Server Process...................................................................... 13
HP-UX 10.20/11.0................................................. 13
Port Number.......................................................... 15
Bugs Fixed 17
Bugs Fixed Since
Version 6.1............................................. 17
Qedit is our
fast and efficient full-screen editor and development home base for HP-UX
systems, both workstations and minicomputers. One of our objectives for Qedit
is to give PowerHouse and COBOL developers all the necessary capabilities to
perform their work from a single program.
We are
constantly enhancing Qedit with new features and fixes requested by users. Not
only does this change notice include a description of Qedit's enhancements, it
includes detailed installation steps and a list of other changes for host-based
Qedit. This change notice also includes a description of the server portion of
Qedit for Windows.
Host-based Qedit
is also available for MPE, with virtually identical features. If you would like
more information, please contact Robelle Solutions Technology Inc.
Our newest
editor, Qedit for Windows, now gives you the familiar Windows interface for
editing both MPE/iX and HP-UX files, all from a single program. Qedit for
Windows is the next generation of our popular editor, which consists of a
Windows editing client and either an MPE/iX or HP-UX editing server that work
together to edit host files. Since its release, we have focused our development
efforts on Qedit for Windows, adding more functionality and continuing to
expand its capabilities. If you would like to upgrade to Qedit for Windows,
please contact Robelle Solutions Technology Inc.
·
The Qedit
Server now supports login via PAM and which supports LDAP.
· The Qedit Server would not properly honour
an adminstrative lock on a user account login.
·
The
Verify command incorrectly parsed certain entries near the end of the verb
table such as ZZ, String etc.
·
Qedit
now recognizes files with the extension of .COB and .cob as Cobol files on
HP-UX.
·
Qedit
on HP-UX now has the command set compatvarsub on which does not replace
$-variables that are not defined with spaces. It simply passes the $token, thru
to the Qedit command interpreter if the variable is not defined.
·
Qedit
now recognizes files with the extension of .COB and .cob as Cobol files on
HP-UX.
·
Qedit
now support long user names on HP-UX 11.31, implemented by lugadmin.
·
Qedit
now supports the HP-UX Long Password feature on HP-UX 11.31. Error messages
have been improved for login issues.
·
Qedit
would return a status code of 123 upon exit even if an error had not occurred.
·
Qedit
for HP-UX would return 123 as a return code even if no error had occurred.
·
Visual
Mode updates would fail with Bad format error if the length of the file was
less than 52.
·
Qedit
did not recognize .cpy files as being Cobol.
·
Regular
Expressions. Qedit would improperly report the error "String longer
than maximum allowed" if the expression specified is longer than the
window of the rangelist.
·
Qedit
for HP-UX did not support Shadow Passwords properly for all versions of HP-UX.
·
A rangelist can now have an AND keyword with up to
10 search strings. All strings must be found on a single line for the line to
be selected. Each string can have its own search window.
· Escape sequences to set/reset terminal tab
stops appear in output file when Qedit's output is redirected as in
$ qedit > qedit.out
Qedit now resets the tab stops when running in interactive mode only.
Redirection is assumed to be batch mode.
The following
enhancements have been implemented in the Qedit for Windows
server.
· The server correctly
returns error 90 when the modified record length is greater than the maximum
allowed in the current workfile.
Qedit/UX is
compatible with most versions of HP-UX 10.20 and later.
IMPORTANT: As of
HP-UX 11.0, HP has dropped support for block-mode terminals. For this reason,
full-screen editing is available in Screen mode or by enabling the Blockemulation option on HP-UX 11.0 and later.
Qedit commands
are added to the Redo stack before variable substitution occurs (Set
Varsub On) i.e. with the
variable name. So, if the variable value changes between the time the command
is entered and the time it is retrieved from the stack, the results may be
different. It's also important to note that commands related to Redo stack
operations such as Listredo,
Do, Before can not have trailing comments enclosed in
curly braces anymore. The comments are not removed and likely cause a syntax
error.
In the examples
in this document, we have used HP-UX 10.20 conventions and assumed Qedit is
installed in the /opt/robelle directory.
Qedit/UX runs
only on CPUs whose serial numbers (the "uname" on HP-UX) have been
encoded. If it fails to run and you see an "invalid HPSUSAN" error
message, call Robelle for assistance.
There
are no known problems at the moment.
Qedit comes with a User Manual and a Change Notice. You may have
received printed copies of these.
They are also available as PDF or HTML files. You can download the
files from the Robelle web site.
The user manual contains the full description of all the Qedit
commands, as well as usage tips. The manual is up-to-date with all the latest
changes incorporated in Qedit. To see only the changes in the latest version,
see the "What's New" section of the manual, or see the change notice.
For a complete
description of the latest changes made to Qedit, the installation instructions,
and any compatibility issues, see the change notice that was included with the
release.
The latest user manual and change notice are available in Adobe
PDF format. If you do not already have the Adobe Acrobat Reader, you can get a
copy from http://www.adobe.com/prodindex/acrobat/readstep.html.
You
can download the files from the Robelle web site at http://www.robelle.com/library/manuals/.
If you are a new Qedit/UX user, please follow the
installation instructions in the Qedit
User Manual. To install this upgrade of Qedit, follow these steps:
1. You must log on as root.
2. Create the correct directory structure.
3. Restore Qedit/UX and its associated files
from the distribution tape.
4. Set up variables to let Qedit know where
some of its supporting files are located.
5. Set up a link between /var/tmp and /usr/tmp
if you are installing on HP-UX 10..x.
6. If you have the Qedit for Windows server,
you need to start the daemon process. (optional)
The installation
should take about half an hour, during which time no one can use Qedit.
If you have any
questions about the upgrade or run into any problems, please call us. Technical support is available on weekdays
from 7 a.m. to 4 p.m., Pacific time.
There are two
ways you can log on as root:
1. Exit from HP-UX and log on with root as the
user name.
2. If you are already logged on, you can
execute this command:
su -
In either case,
you have to know and supply the user password for root.
Before restoring
files, you must first create the directory in which Qedit will reside:
Use the
following command to restore the Qedit/UX files from the distribution tape:
This command
assumes your tape device is /dev/rmt/0m. If it is not, you need to specify your
tape device using the "f" option in the tar command. For example, if your tape device is
/dev/rmt/1m, you need to use the following command to restore the files:
tar xvf /dev/rmt/1m /opt/robelle
You can set up
numerous variables to make running any of the Robelle products easier.
The three
variables that we recommend setting are ROBELLE, PATH and MANPATH.
· The ROBELLE variable tells the Robelle
products where it's supporting files are located.
· The PATH variable, when set, allows the
user to run Qedit by just typing "qedit" instead of the fully
qualified program name.
· The MANPATH variable, when set, allows
users to access the manpage (Help page) for Qedit.
You can invoke
Qedit with the following command:
The easiest way
to add variables accessible to all users is to set the variables in the global
exec file for the shell you use.
For the Bourne
and Korn Shells we recommend the following additions:
export ROBELLE=/opt/robelle
export
PATH=$PATH: $ROBELLE/bin
export
MANPATH=$MANPATH: $ROBELLE/man
Remember to
delete any PATH or MANPATH settings in /etc/d.profile, so that new users do not
override your changes. You also have to warn existing Bourne and Korn shell
users to change their .profile file in their home directories.
For the C Shell
we recommend that you add the following commands after any existing PATH or
MANPATH statements in the /etc/csh.login file:
setenv ROBELLE /opt/robelle
set
path=($path $ROBELLE/bin)
setenv
MANPATH "$MANPATH": $ROBELLE/man
Remember to
delete any PATH or MANPATH settings in both /etc/d.login and /etc/d.schrc, so
that new users do not override your changes. You also have to warn existing C
shell users to change their .login and .cshrc files in their home directories.
When you run
Qedit, it creates and uses certain temporary files. On HP-UX 10.x systems, temporary files are generally
created in the /var/tmp directory. To get Qedit to keep an undo log and redo
stack, you must set up a link between /usr/tmp and /var/tmp. To check whether
this has already been done, enter
If a link
exists, you will see a line such as this:
lrwxrwxr-t 1 root sys 8 Aug
16 1996 /usr/tmp -> /var/tmp
If the link is
not set up, you can create it by entering
If you have the
Qedit for Windows server software, you must start the Qedit/UX daemon process
before any Qedit clients can connect to your HP-UX machine. To allow users to connect to the Qedit/UX
daemon process, you must log on as root and issue this command:
The Qedit server
process requires three log files. By
default, these files are located in the following directory:
If you have
moved Qedit to a different directory, you will have to perform the following
steps:
1. Set the ROBELLE environment variable with
the new directory name before you start the Qedit server process.
2. Make sure the new directory has exactly the
same structure as the /opt/robelle directory.
The following
sections describe the new enhancements to Qedit/UX since the last major
release. The number in brackets at the end of each section indicates the
version in which the feature was first introduced.
·
A rangelist can now have an AND keyword with up to
10 search strings. All strings must be found on a single line for the line to
be selected. Each string can have its own search window. [5.6.10]
Qedit for
Windows lets you edit local MPE/iX and HP-UX files from a single MS Windows
program. It consists of a Windows editing client and either an MPE/iX or HP-UX
editing server that work together to edit your host files. To take advantage of
Qedit for Windows, you need both the Qedit client and the Qedit server.
Qedit for
Windows uses the popular TCP/IP protocol for communicating between the client
and the server (this is the same protocol that you use to access the Web). Configuring the Qedit server software
requires creating the correct TCP/IP environment for Qedit for Windows.
Qedit clients
can connect to Qedit/UX only if the Qedit/UX daemon process is running (the
Qedit/UX daemon process cannot be started from inetd). This process listens for connections on a
registered port number (described below).
To allow users to connect to the Qedit/UX daemon process, you must log
on as root and issue this command:
The Qedit/UX
daemon process should always be running, so it is a good idea to automatically
start the daemon as part of the system startup process. On HP-UX 9.0, this is
done by adding the following command to the file /etc/rc:
/opt/robelle/bin/qedit -d
On HP-UX 10.20
and up, you do not modify the startup shell script. Instead, you need to create a number of
files. The HP-UX documentation states that the following characters cannot be
used as part of the file names: [.,~#]. Otherwise, you can choose any name for
these files, as long as the names are consistent throughout the process. In our
example, we use qedit_server.
You first need
to create a control file in /etc/rc.config.d.
This file sets a control variable that will be checked by the startup
script. If the control variable is set to 1, the server will start; if it is
not equal to 1, the server will not start.
We will use QEDIT_SERVER as our variable name. The /etc/rc.config.d/qedit_server control
file will now contain the following:
# ****** File:
/etc/rc.config.d/qedit_server ******
#
Qedit for Windows server configuration.
#
#
QEDIT_SERVER: Set to 1 to start
# Qedit for Windows server
QEDIT_SERVER=1
Next, you need a
shell script that will actually start the server. You can copy a template of
the shell script from /sbin/init.d/template.
cd /sbin/init.d
cp
template qedit_server
Modify the file
so that it contains the necessary commands to start the server. You have to
change all occurrences of CONTROL_VARIABLE to the variable name you used in the
control file (i.e., QEDIT_SERVER).
You also need
the execute command for the server program.
Insert this command (underlined below) in the section after the 'start')
string. The section looks like this:
'start')
# source the system configuration
variables
if [ -f /etc/rc.config ] ; then
. /etc/rc.config
else
echo "ERROR: /etc/rc.config
defaults file MISSING"
fi
# Check to see if this script is allowed
to run...
if [ "$QEDIT_SERVER" != 1 ];
then
rval=2
else
# Execute the commands to start your
subsystem
/opt/robelle/bin/qedit -d
fi
;;
Finally, you
need a symbolic link to specify when the script in /sbin/init.d will be
executed at boot time. Typically, you would start the server as the last step
at run level 3. Get a list of all the
startup files in /sbin/rc3.d with
Link names in
this directory follow a set of conventions. The names start with the letter S or K.
S links are startup scripts; K links are shutdown or "kill"
scripts. The next three characters in
the name represent an execution sequence number. This number must be 3 digits,
and its value should be a number greater than the highest value on the ls
listing. For example, if the last link
is called S100nfs.server, you could use S111qedit_server. Create the symbolic link with
ln -s /sbin/init.d/qedit_server /sbin/rc3.d/S111qedit_server
For the time
being, you do not need a "kill" link.
By default,
Qedit/UX listens on port number 7395.
This port number has been registered with the Internet Naming Authority,
so you should not have any conflicts with other HP-UX tools for the same port
number. If there is a conflict, you can start
the Qedit server process with a different port number. For example,
tells Qedit to
listen to port number 5678 instead of the default number (7395). If you change the port number on the Qedit/UX
server, you must also change the port number on every Qedit client to the same
value (5678 in this example). Client
port numbers can be changed in the Server Settings dialog box of the Options
menu.
If you want
listings from netstat and other networking tools to identify the port number as
"qwin" instead of just "7395," you have to change the
/etc/services file so that it includes the Qedit port number.
qwin 7395/tcp #Robelle Qedit for Windows
The following
problems have been fixed since the last production version.
·
The Qedit server would not properly honour an
administrative lock on a user account, during login from the Qedit for Windows
client. [6.1.01]
