Use Suprtool/AMXW to read, select, and
sort data from Oracle, Allbase and Eloquence databases and data files with
fixed-length records. Suprtool/AMXW is designed to be similar to Suprtool for
MPE while providing necessary HP-UX features. It is designed to work with AMXW
an MPE environment from Speedware that runs on other platforms.
Suprlink/AMXW provides high-speed
data-file linking based on a sort key. Use STExport for AMXW to convert fields
in a self-describing input file into an output file that can be imported into
different applications.
·
Suprtool did not properly clear
the data field information from a table at the end of a task.
·
Suprtool did not properly zero
out a packed field target when an table entry was not found when extracting
data from a table.
·
Suprtool for HP-UX on Itanium
now has proper support for $atoe and $etoa.(Itanium version Only)
·
Suprtool for AMXW would fail
with FSERR 40 when attempting to append to a "KSAM" file.
·
Suprtool for HP-UX on Itanium
had problems with reading files with record sizes greater than 13700 bytes.
·
Suprtool for HP-UX on Itanium
would incorrectly coerce the number negative
65536 from Binary to Decimal and Decimal to Binary. (Itanium version Only)
·
Suprtool for AMXW would not run
an external program from inside Suprtool due to a naming conflict with some
routines in the AMXW libraries, this is the Itanium version only.
·
Suprtool for AMXW would not
sort a file properly if the output file size was 32 bytes and a blocking factor
of 16, the input file was larger and using Suprtool 5.2.12 and higher linked
with AcuVision. (Fixed in Build 4)
·
Suprtool for AMXW would not
sort a file properly if the output file size was 32 bytes and a blocking factor
of 16, the input file was larger and using Suprtool 5.2.12 and higher linked
with AcuVision. (Fixed in Build 4)
·
Suprtool for AMXW now supports
output ,append access to vision file system KSAM.
·
The Add command which adds an
input file to an Oracle table now allows for the syntax of ownername.tablename.
·
A Select operation on an empty
table or if the select would result in zero records it would fail if Set
Ifouroutput was on. This was for the Itanium version only.
·
Suprtool would not properly
store the number of bits to store on a bitwise operation in the if command or
extract. (Itanium only)
·
The chain command would not
work if a data set entry length was evenly divisable by 128. (Itanium only)
·
Extract to a Logical target
would produce a zero result. (Itanium only)
·
An extract with a arithmetic
divide would not round properly if the target field was an single-integer,
double-integer, quad-integer, single-logical or double logicals. (Itanium only)
·
Suprtool would fail with Stack
Overflow message or simply fail when loading a table with the sorted option if
the key data type was a double-integer, small integer or small logical.
(Itanium only)
·
An extract operation where the
target was a single integer and the source was a double integer would not work
properly. (Itanium only)
·
Set Oracle SpaceNull has been
added to convert byte, char and date fields when Null to spaces or leave them
as null. If SpaceNull is on, then spaces will be placed in the fields. If
SpaceNull is off then the field will contain nulls.
·
Suprtool did not properly
coerce data from Packed to Quad integer when using Set Ifouroutput on and Set
Oracle Integer on. (Itanium only)
·
Set Oracle Passshift Off now
turns off password upshift for the oneline syntax method when you are including
the service name.
·
The Dup None Keys Count command
didn't write out an extended name if Set SDExtname On. This was an issue in the
Itanium version only and was fixed in Build 2.
·
STExport did not properly
handle the Delimiter Tab option. Fixed in STExport (Build 2).
·
The verify command could
potentially corrupt the internals of STExport and cause a core abort. (Build 3)
·
Suprtool Itanium Build 4 did
not have some areas enabled for Large Files. (Fixed in Build 5)
·
Suprtool did not coerce
properly from Packed to Quad integer when using Set Oracle Integer on and Set
Ifouroutput on. It would improperly round a number up by one. This was for some
numbers greater than 16 digits. (Itanium Only Fixed in Build Six)
·
Suprtools Table command would
not find a field in the Table file when using Set SDExtname On. (Itanium Only
Fixed in Build Six)
·
STExport now has Set ZonedFix
On, this setting can be used to zero out any zoned fields that were unable to
be converted from zoned to byte and typically have a "?" in the
result. This is often caused by hidden characters or bad data.
·
Suprtool now has Set Oracle
PassShift On (default) or Off to turn off the upshift of a password. This is to
accomodate Oracle 11 which will allow for case-sensitive passwords.
·
The Add command in Suprtool for
HP-UX would cause a subsequent task to fail in some cases.
·
The Add command in Suprtool for
HP-UX would fail if the target was a small record.
·
Suprtool, STExport, Suprlink
and Suprcall are all available as a Native Itanium binaries
·
Suprtool now has the command
set list formfeed on, which will put a formfeed at the end of the file when
using the list command with the file option. This allows multiple reports to be
written to one file and have them line up on a page break.
·
Suprtools $edit function now
accepts the colon character as a delimiter character in order for edit masks
for time fields.
·
Suprtools if command would not
allow a field name starting with SPECIAL if it was on the right side of the
equation.
·
The Base command would not pass
the database name to be parsed if it was preceded by a command without any
parameters. (Itanium Build 2)
There are no known problems at this time.
If you have any questions or concerns or feedback, please feel free to e-mail
me at: neil@robelle.com
There are two types of machines that HP
has that run HP-UX, the older machines are based on the PA_RISC chip and the
new machines that use the Itanium (and Itanium 2 chips). There are also program
files that are specific to each chip. PA_RISC programs can run on both PA_RISC
and Itanium machines, however, Itanium programs can only run on Itanium
machines.
Any program that runs on Itanium must
utilize libraries that match its own program type. Therefore if a PA_RISC
program runs on Itanium and looks for a library, it must find/load the PA_RISC
version of the libraries that it needs and conversely an Itanium program must
load the libraries specific to its type.
How
to Tell what Machine I am on?
There are many ways to tell what kind of
machine you are on, here are a couple:
uname -m
getconf MACHINE_MODEL
In each case the Itanium machine will
typically say ia64 somewhere in the result of the above two commands. PA_RISC
machines typically say "9000" somewhere in the string.
What
is the Program File Type?
Since there are two types of machines
there are also at least two types of program files. Suprtool is primarily
either PA_RISC 1.1 or ELF-32 / IA64 which is also known as Itanium. To
determine the type of program file you can use the file command:
Itanium
file suprtool
suprtool: ELF-32 executable object file - IA64
PA_RISC
file suprtool
suprtool: PA-RISC1.1 executable dynamically linked
-not stripped
The PA_RISC binary can run on both
platforms but you need to have PA_RISC libraries for Eloquence or Oracle if you
are using the Oracle module. An Itanium binary will not run on a PA_RISC
machine and will fail with "cannot execute".
Of
course we've made a provision to identify if you are running the ia version
of Suprtool in the banner and verify command with the ia after the UX :
SUPRTOOL/UXia/Copyright
Robelle Solutions Technology Inc. 1981-2009.
(Version 5.2
Internal) MON, JUN 8, 2009, 11:26 AM Type H for help.
PA_RISC
Loading
Suprtool by default looks in the
libraries in any of the directories named in SHLIB_PATH. For example to insure that Suprtool resolves
the library loads you can set the SHLIB_PATH
system wide in your /etc/profile file in the following manner:
export SHLIB_PATH=/opt/eloquence6/lib/pa11_32:/opt/oracle/lib
If you do not have the SHLIB_PATH
variable set to a value where the libraries can be found, Suprtool will then
try to load from their default names locations.
For Eloquence the default location is :/opt/eloquence6/lib/pa11_32.
The Oracle interface will first try to
load libclntsh.so and then attempt to load libclntsh.sl from
$ORACLE_HOME/lib32/libclntsh.sl.
Itanium
Loading
You can change Suprtool to pay attention
to LD_LIBRARY_PATH and use dlopen to load libraries, you can set the
environment variable:
export ROBELLE_DYN_LOAD
=Y.
It is generally advisable to use DLOPEN
or the ROBELLE_DYN_LOAD option when using the Itanium version. The PA_RISC
version of Suprtool can use either type
of loading, the default or the dlopen method invoked with ROBELLE_DYN_LOAD.
Running
the PA_RISC version on Itanium:
You can of course run the PA_RISC version
of Suprtool, however, given that the PA_RISC version requires SHLIB_PATH to
point to PA_RISC libraries may go against the configuration necessary for other
programs that may need SHLIB_PATH to point to Native Itanium libraries.
The solution to this is fairly simple,
you can create a command file (let's say /opt/robelle/cmd/suprtool) that runs
suprtool for you, of course you need to insure your path variable has
/opt/robelle/cmd before /opt/robelle/bin.
You can then have the following commands
in the /opt/robelle/cmd/suprtool command file:
export
SAVED_SHLIB_PATH=$SHLIB_PATH
export
SHLIB_PATH=/opt/oracle/pa_risc/lib:/opt/eloquence/lib/pa11_32
/opt/robelle/bin/suprtool
$@
export
SHLIB_PATH=$SAVED_SHLIB
Essentially all it does save the current
SHLIB_PATH setting, sets it to point to PA_RISC libraries, runs suprtool and
then resets the library back.
Suprtool
for Itanium
Now that you know all about PA_RISC and
Itanium you do need to be aware of what Suprtool for Itanium is in terms of new
code and risk for potential issues. Suprtool for Itanium is completely in C
code. This does not mean that it is all new C code however, the majority of the
Suprtool code is still based on SPL, but is converted to C, using Allegro's
SPLASH compiler.
So while the C code is new it is based on
the original SPLash code, however, given differences between C and SPLash not
all code can be automatically converted in some cases. We worked closely with
Allegro to find ways to have the source code work and address the various
issues that came up. The entire time Allegro improved the SPLash to C
converter.
So while we are based on the original
Suprtool we do have new code paths in the Native Itanium version and other
potential issues where the C code might not work in exactly the same manner as
the SPLash code.
Having said that we have tested this
against our test suites, and improved and added a large number of tests to our
HP-UX test suites. We also began Alpha testing 24 months ago and have been beta
testing for the last year with our two best VAR customers.
Suprtool for AMXW would use the file
size stored in the SD label as opposed to the actual physical file size that
AMXW uses.
::FILE
FILE80;REC=-80,,F,ASCII
::supramxw
SUPRTOOL/AMXW/Copyright Robelle Solutions Technology Inc.1981-2007.
(Version 5.0) TUE, JAN
08, 2008, 2:42 PM
Type H for help.
>I STFILE
>DEF ABCXYZ,1,11
>EXT ABCXYZ
>O FILE80,LINK
>X
IN=26, OUT=26. CPU-Sec=1. Wall-Sec=1.
>FO FILE80
File: FILE80 (SD Version B.00.00) No linefeeds
Entry:
Offset
ABCXYZ
X11 1
Limit: 1023 EOF: 26 Entry Length: 11 Blocking: 1
>E
::LISTF FILE80,2
ACCOUNT=
AMXWQA GROUP= FDE
FILENAME
CODE ------------LOGICAL RECORD----------- ----SPACE----
SIZE TYP
EOF LIMIT R/B SECTORS #X MX
FILE80
1084 82B
FA
26 1023
1 9 1 *
So what happens is if an output link
file is created with a file equation making the file bigger, any subsequent
files that are created from the resulting output file are actually made smaller
as you can see below.
::supramxw
SUPRTOOL/AMXW/Copyright Robelle Solutions Technology Inc.1981-2007.
(Version 5.0) TUE, JAN
08, 2008, 2:42 PM
Type H for help.
>i FILE80
>O FILE80A
>X
Warning: Using Output FILE80A,Link
IN=26, OUT=26. CPU-Sec=1. Wall-Sec=1.
>E
::LISTF FILE80A,2
ACCOUNT=
AMXWQA GROUP= FDE
FILENAME
CODE ------------LOGICAL RECORD----------- ----SPACE----
SIZE TYP
EOF LIMIT R/B SECTORS #X MX
FILE80A
1084 11B
FA
26 1023
1 2 1 *
Suprtool for AMXW now honours
the physical record size and the FILE80A file will now have a record size of
80.
The HP-UX and AMXW versions of AMXW no
longer have Set varsubcompat on as the default.
The default is now off and can be turned on with the set command or the
–cv option.
Previously, Suprtool would treat an “R”
type field in an Eloquence database as an R type while the data inside
Eloquence is stored and treated as IEEE
therefore incorrect results would occur with coercions and arithmetic
operations. Suprtool now by default maps all Real and Long fields to their
respective IEEE fields. You can change Suprtool back to the previous
behaviour with Set RealMap Off.
A form command will still show the fields
as being “R2” or “R4”, but internally Suprtool will treat as IEEE, which is how
Eloquence stores and treats the numbers.
Consequently STExport will now support
items in SD files that are condidered R type, however it correctly will map
them to IEEE.
Suprtool/UX 5.0 is now compatible with all
versions of HP-UX 11.2x, as well as Oracle version 8 and higher.
Suprtool/UX version 4.8.02 and lower is
compatible with HP-UX 9.0 and higher and Oracle 7.
Fastread option is now set to On for
Suprtool for HP-UX the regular version. The Dynamic loading version of Suprtool
has a default value of off to start.
Suprtool 5.2 is necessary for use with
Oracle 11 and case sensitive passwords.
There are a couple of differences in the
Itanium version of Suprtool, which you need to be aware of.
The
DBEdit module is not available in the Itanium versions of Suprtool. This module
is invoked by the EDIT command.
The
layout for the Verify command is slightly different then the PA-RISC versions
of Suprtool.
This program runs only on CPUs whose
serial numbers have been encoded (the "uname" on HP-UX). If it fails
to run and you get an "invalid HPSUSAN" error message, contact
Robelle for assistance, via support@robelle.com
or the support number at 1-800-453-8970.
The
user manual contains the full description of all the Suprtool suite of products
including Dbedit, Suprlink, STExport, and Suprtool2, as well as usage tips and
commands for each. The manuals are up-to-date with all the latest changes. To
see only the changes in the latest version, see the "What's New"
section of the manual.
You
can download our manuals and Change Notices in various formats and order
printed (hardcopy) manuals from our web site at:
http://www.robelle.com/library/manuals/.
The following instructions describe the
installation process of a new Suprtool release. The new version overwrites an
existing version of Suprtool on your HP-UX system.
There are typically two main types of
installations. You can find the Suprtool for AMXW regular install instructions
here:
http://www.robelle.com/downloads/install-amxwprod.html
You can find the Suprtool for AMXW build
on your system instructions on the link below. You will need this install if
you are going to require the KSAM option, Dynamic Image loading or Omnidex
support, or intend to run on Itanium:
http://www.robelle.com/downloads/install-amxwbuildprod.html
If you have any questions or run into any
problems, please call us. Technical support is available on weekdays from 8 a.m. to 4 p.m. Pacific time at 1.800.453.8970. Technical
support can also be obtained via e-mail at: support@robelle.com If your new version of software will not run,
you can page someone from technical support by calling the 1.800 number, or you
can typically easily run extend with the disaster option to tide you over until
business hours. Instructions for this are available at:
http://www.robelle.com/disaster/
Suprtool
is constantly being updated with new features. The following section describes
the new enhancements to Suprtool since Suprtool 5.3
The algorithm for Eloquence routine
loading has changed slightly on Itanium. Suprtool will attempt to load hpux32/libimage3k.sl
and hpux32/libeqdb.sl on the second attempt to load the libraries. The
algorithm is that Suprtool will first try to load the files individually, then
hpux32/libimage3k.sl and then an attempt at the fully qualified filename.
Suprtool
is constantly being updated with new features.
The Add command which allows for adding
data to an Oracle table now allows for the syntax of Ownername.Tablename. The
single syntax of just giving the table name will work as it always has.
Suprtool has a new setting called Set
Oracle SpaceNull, which when on puts spaces in any byte, Char or Date (Oracle
Date) fields instead of the nulls. The default behaviour is off.
Suprtool now has the command Set Oracle
PassShift Off which turns off the default behaviour of upshifting Oracle
passwords. This is to accomodate Oracle 11 which allows case sensitive
passwords. The first pass on this was to allow the syntax of:
open oracle suprtest
suprpass
We
now honour Set Oracle PassShift for the syntax that includes the service name:
open oracle
suprtest/suprpass@servname
STExport now has Set ZonedFix On, this
setting can be used to zero out any zoned fields that were unable to be
converted from zoned to byte and typically have a "?" in the result.
This is often caused by hidden characters or bad data.
Suprtool now has the command Set Oracle
PassShift Off which turns off the default behaviour of upshifting Oracle
passwords. This is to accomodate Oracle 11 which allows case sensitive
passwords.
Suprtool, STExport and Suprlink are now
available as Native Itanium. This represents a complete conversion of all
Suprtool code to the C language. This version has many of the same components,
with the exception of Dbedit. This conversion allows us to port to other
platforms such as AIX and any other platforms.
If you are interested in a particular platform please contact neil@robelle.com.
Packed Data. Suprtool for
HP-UX on Itanium would incorrectly coerce the number negative 65536 from Binary to Decimal and
Decimal to Binary.
External Programs.. An external program
would fail to be loaded to run when attempted to be run from inside Suprtool
Itanium
Table Command. Suprtool
did not properly clear the data field information from a table at the end of a
task.
Extract from Table.
Suprtool did not properly zero out a packed field target when an table entry
was not found when extracting data from a table and the Packed field was P12 or
higher.
Large Files. Suprtool
Itanium Build 4 did not have some modules compile to support Large Files.
(Fixed in Build 5)
Sort with specific sized output file. Suprtool for AMXW would not sort a file properly if the output file
size was 32 bytes and a blocking factor of 16, the input file was larger and
using Suprtool 5.2.12 and higher linked with AcuVision
STexport Abort. STExport
would potentially abort after the verify command had been specified after an
input or output command. Fixed in Build 3. (Itanium only).
STexport Delimiter.
STExport did not properly write a tab between fields when using Delimiter Tab.
Fixed in Build 2. (Itanium only).
Extract. Suprtool did not
properly coerce a double integer into a single integer.
Table Sorted. Suprtool
would fail with a Stack Overflow or simply fail when using the Table command
with the sorted option if the key value was a double integer, single integer or
a single logical.
Set Ifouroutput and Set Oracle Integer. Suprtool did not coerce properly from Packed to Quad integer when
using Set Oracle Integer on and Set Ifouroutput on. It would improperly round a
number up by one. This was for some numbers greater than 16 digits. (Itanium
Only Fixed in Build Six)
Table Command. Suprtools
Table command would not find a field in the Table file when using Set SDExtname
On. (Itanium Only Fixed in Build Six)
